Bluetooth Makes Things Simple

Get rid of complicated cables. The upgraded speakerphone’s Bluetooth capability makes connecting to tablets and mobile phones easy, and it keeps your conference room clean so you can make a strong impression.

vc540

AVer SmartFrame Gets Your Meetings Started Fast

The VC540 delivers the efficiency of AVer SmartFrame to your meeting room. SmartFrame maximizes the viewable field with an auto-framing solution that quickly and effortlessly puts everyone in your meeting into frame.

VC540

Professional Clarity with a 16X total Zoom

Enhance your communication by showing every detail precisely and smoothly. The VC540 is embedded with a 16X total zoom and multi-coated autofocus optics to present complex product details in crystal-clear quality.

vc540

Cutting-Edge 4K Ultra HD

The VC540 uses a Sony™ high-quality sensor and multi-lens glass to provide the sharpest video possible. Also, an advanced image-processing engine allows you to display natural, vividly colored details even in challenging lighting conditions and on very low-latency networks.

Before
After

Hardware Spec

  • 1DC 12V
  • 2RS232 in/out
  • 3USB 3.1 Type-C
  • 4Reset
  • 1Phone in
  • 2Daisy-chain up to 3 speakerphones or 4 microphones
  • 3Line out
  • 4Micro USB 2.0
  • 5LAN for IP remote access
  • 6DC 12V

Specifications

  • Camera
    • Ultra-crystal-clear image support up to 4K
    • Frame rate: 4K, 1080p, 720p, 640 x 480, 320 x 240
    • SmartFrame: automatic FOV adjustment to fit all participants
    • 16X zoom
    • Autofocus: minimum working distance 1 meter
    • 86° horizontal field of view
    • Backlight compensation and 2D noise reduction technology for optimizing light balance in varying conditions
    • Standard tripod screw holes
    • Analytics API: enterprises and third-party software providers can obtain people-counting data to better understand meeting-space usage
  • Speakerphone
    • Bluetooth / USB Wired
    • Full-duplex microphone array with echo cancellation
    • Advanced noise suppression
    • 2-microphone array
    • 3.5 mm phone-in Jack
    • 3.5 mm line out
    • Speaker volume: adjustable to 90 dB SPL at 0.5 m
    • Touch controls for volume down/up, mute, phone input, call, and hang up
    • Can bridge phone-in and USB into one call
    • Security: Kensington slot
  • Motorized Pan & Tilt Movement
    • Pan: ±160°
    • Tilt: +90° (up) -30° (down)
    • 10 camera presets (via remote control)
    • Fast and quiet pan & tilt movement
  • Connectivity
    • Mini DIN 6 for RS232 connector for camera
    • USB Type-C connector for camera
    • Micro USB connector for speakerphone
    • IP (RJ45) connector for speakerphone
    • Bluetooth for speakerphone
  • Video Format
    • YUV, MJPEG
  • USB
    • 2.0, 3.1 Gen1
    • UVC (USB Video Class) 1.1
    • UAC (USB Audio Class) 1.0
  • Control
    • IR remote control
    • VISCA/pelco and P/pelco D via RS232
    • UVC/plug-and-play
    • PTZApp
  • Optional Accessories
    • Mini DIN 6 to RS232 adapter for camera
    • Expansion Speakerphone (10 m cable included, daisy-chain up to three speakerphones)
    • Expansion Pair Microphone (Two 5 m cables included, daisy-chain up to four microphones)
    • USB 2.0 type-C to type-A Cable (16 ft)
  • Warranty**
    • Camera/Speakerphone: 3+2 years
    • Accessories: 1 year
  • Security and Mount
    • Camera mount included for wall or ceiling
    • Kensington slot
  • System Requirements*
    • Windows® 7/10 or later
    • Mac OS X v10.13 or later
    • Google Chromebook™ version 76.0.3809.102 or later
    • Android™ 6 or later
  • Hardware Specifications*
    • Processor: 3.2 GHz Intel® Core™i5-4460 or later
    • 4 GB RAM
    • USB 3.1 port, backward compatible with USB 2.0 port
  • Free Applications for Meeting Collaboration (for Windows® and Mac Devices)
    PTZApp
    • Upgrade firmware automatically or manually
    • Control camera
    • Set parameters and adjust camera image
    • Diagnose operating status
    • View live video
    EZLive
    • Real-time streaming / annotating / snapshots /video recording
  • Environmental Data
    • Operation temperature: 0°C ~ 40°C
    • Operation humidity: 20% ~ 80%
    • Storage temperature: -20°C ~ 60°C
    • Storage humidity: 20% ~ 80%
  • Dimensions
    • Package dimensions: 259 x 259 x 349 mm
    • Package weight: 4.6 kg
    • Camera: 130.7 x 97.8 x 171.1 mm
    • Speakerphone: 220 x 181.5 x 49.5 mm
    • Remote control: 200 x 50 x 21 mm
  • Package Contents
    • CAM540 Camera
    • Speakerphone
    • Remote control
    • Power adapter x 2
    • Power cord (6 ft)
    • USB 3.1 type-C to type-A Cable (6 ft)
    • Micro USB 2.0 to Type-A cable (16 ft)
    • 3.5 mm aux cable (3 ft)
    • Warranty card
    • Quick Start Guide
    • Metal mount, tripod screws
    • Batteries
  • Compatible Applications
    • Zoom, Microsoft® Teams, Skype for Business, Skype, Google Meet, Intel® Unite™, RingCentral, BlueJeans, V-Cube, LiveOn, CyberLink U Meeting ®, TrueConf, Adobe® Connect™, Cisco Webex®, Fuze, GoToMeeting™, Vidyo, vMix, WebRTC, Wirecast, XSplit

* For 4K UHD support, please check your system/hardware requirements with your software application provider.
** Please register online to receive a free 2-year warranty extension. For detailed warranty information, please contact an AVer representative.
*** Specifications may vary depending on location and are subject to change without notice.

URL

Accessories

  • Expansion Speakerphone incl. 10m cablePN:60U0100000AB

    Optional:

    Expansion Speakerphone incl. 10m cable
  • Expansion Microphone pair incl. 5m cablePN:60U0100000AC

    Optional:

    Expansion Microphone pair incl. 5m cable
  • Expansion Speakerphone / Mic cablePN:064AOTHERCD5

    Optional:

    Expansion Speakerphone / Mic cable (20m)
  • 10M USB 3.1 extension cable PN:064AUSB−−CC5

    Optional:

    10M USB 3.1 extension cable (fiber, Type A to A) *
  • 20M USB 3.1 extension cable PN:064AUSB−−CC6

    Optional:

    20M USB 3.1 extension cable (fiber, Type A to A) *
  • 30M USB 3.1 extension cable PN:064AUSB−−CDS

    Optional:

    30M USB 3.1 extension cable (fiber, Type A to A) *
  • 5M USB 2.0 extension cable(Type C to A) PN:064AUSB−−CBE

    Optional:

    5M USB 2.0 extension cable (Type C to A)
  • Mini DIN6 to RS232 adapter PN:064AOTHERB66

    Optional:

    Mini DIN6 to RS232 adapter
  • Foldable TV mount PN:060V2C10000A7

    Optional:

    Foldable TV mount
  • * Please contact local authorized dealer/distributor for purchasing optional accessories.
