All-in-One 4K PTZ Technology Offers Vivid Imagery

The VB342 Pro is equipped with a comprehensive 4K PTZ camera; delivering vivid images in any meeting. 92° FOV optical lens with 15X zoom delivers true-to-life video quality. 6W*2 speakers provide outstanding sound for small and mid-size rooms

VB342 Pro
  • 3X Optical Zoom
  • 15X Total Zoom
  • 92° FOV
Tilt: ±15° Pan: ±35° VB342 Pro

Auto Frame and Audio Tracking Enhance Meeting Efficiency

Audio Tracking and Auto Frame smart AVer AI automatically focuses and detects all groups and speakers in the room, offering optimal performance for any virtual business meeting. Sound detection technology singles out human voices and enables intelligent AI functionality.
Auto Frame Audio Tracking

VB342 Pro

Deliver Detail-Oriented Presentations with Presentation Tracking

Through a combination of audio tracking and audio preset tracking AI technology, when the presenter speaks, the VB342 Pro will locate and frame the area. Should the presenter move, the VB342 Pro will track and zoom to provide the best possible image, even outside of the preset location.
Presentation Tracking

VB342 Pro

Smart Gallery Upgrades the Meeting Experience

Offer the remote site clear views of every participant with Smart Gallery, which enables AI face and body detection technology to crop participants’ faces and make sure everyone is looking great. You can choose between headshot and half body mode to adapt to any situation without compromise.
Smart Gallery

*Please enable this function via PTZApp 2.
**Smart Gallery supports up to 20 participants.

Uninterrupted Clarity created by Audio Fence and Beamforming Technology

Silence any distraction outside of the viewing angle with AVer Audio Fence technology and turn any space into an uninterrupted meeting zone. Combine with Beamforming Technology to ensure resonant sound and clear participant voices. Virtual conference better with the VB342 Pro.

VB342 Pro
VB342 Pro
Configuration
  • Expansion speakerphones and expansion microphones are optional accessories.
  • Expansion speakerphones and expansion microphones don’t support daisy chain.
Expansion speakerphones
Expansion microphones
10m / 20m
10m / 20m
VB342 Pro

Product Overview

  • 1 PTZ lens
  • 2 LED indicator
  • 1 USB 2.0 Type A for wireless dongle
  • 2 Audio expansion
  • 3 RS-232
  • 4 Phone in/ Speaker out
  • 5 USB 2.0 Type-A USB
  • 6 HDMI out (to TV)
  • 7 USB3 Type-B (device to PC)
  • 8 LAN
  • 9 DC 12V

Specifications

  • Camera
    • 4K 3X optical zoom lens with 15X zoom
    • Field of view (D/H/V): 92°/84°/53°
    • Sony 4K True WDR sensor: ultra-crystal-clear image in any lighting
    • Frame rate: (16:9) 4K 30fps; 1920 x 1080, 1600 x 900, 1280 x 720, 960 x 540, 848 x 480, 800 x 448, 640 x 360 at 60, 30, 15fps; (4:3) 1280 x 960, 800 x 600, 640 x 480, 480 x 360 at 60, 30, 15fps
    • Adjustable audio fence: Block outside noise; freely define your meeting area
    • True WDR up to 120db: Superb backlight compensation technology for optimizing light balance in high-contrast conditions
    • SmartFrame & SmartSpeaker: automatic tracking and field of view adjustment to fit all participants and focus on the speaker
    • Presentation tracking: Tracking speaker with both preset area and participant tracking
    • Smart gallery* function for great visibility
    • Gesture control for intuitive camera control
    • Mirror, Flip, AE, white balance: Auto, manual override via PTZApp 2
    • Minimum focus distance: 80 cm
    • People counting API: Enterprises and third-party software providers can obtain people-counting data and meeting interval for better understanding of meeting space usage

    *Please download PTZApp 2 to set up Smart gallery function
  • Motorized Pan and Tilt Movement
    • Pan: total horizontal viewing area 180°
    • Tilt: total vertical viewing area 105°
    • 10 camera presets (via remote control and IP web page)
  • Video Format
    • YUV, YUY2, M-JPEG
    • Network video compression formats: H.264, H.265
  • USB
    • 3.1 Gen 1, backward compatible with USB 2.0
    • UVC 1.1 (USB Video); UAC 1.0 (USB Audio); UVC 1.5*

    *For UVC1.5, it involves in different platform environment and requires extra FW upgrade. Please contact technical support for more details.
  • Control
    • IR remote control
    • WebUI: IP access via Chrome browser (Chrome 76.x or later; Internet Explorer not supported)
    • VISCA/pelco P/pelco D via RS-232; Visca over IP
    • UVC/UVA plug-and-play
    • PTZApp 2
  • Mount and Security
    • Camera wall-mount bracket included
    • TV VESA mount kit (optional)
    • Foldable TV mount (optional)
    • Kensington security lock
  • System Requirement
    Software
    • Windows® 7/10/11
    • MacOS 10.14 or later
    • Chromebox 3 version 94.0.4606.114 or later
    Hardware
    • 3.2 GHz Intel® Core™ i5-4460 processor
    • 4 GB RAM or more
    • USB 3.1 port, backward compatible with USB 2.0
  • Power Supply
    • AC 100V–240V, 50/60 Hz
    • Consumption: 12V/5A
  • Free Applications for Meeting Collaboration (Free Apps support on Windows® and Mac® computers)
    EZManager 2: Camera Central Management Software
    • Remotely group FW/SW upgrades, control the camera, and manage settings
    PTZApp 2: Camera setting software
    • View live video, people counting number, meeting interval information
    • Enable Skype for Business far-end control
    • Upgrade firmware automatically or manually
    • Control the camera
    • Set parameters and adjust the camera image
    • Diagnose operating status
    • Smart gallery/ Virtual USB streaming/ Preset Link
    EZLive: Broadcasting software
    • Enjoy multi-camera real-time streaming, annotating, image capturing, and video recording
  • Audio
    • 10-element beamforming microphone array
    • 8 meters (27 ft) pickup range
    • Stereo speaker with output power 12W (6W x 2 pcs)
    • Volume up to 96 dB SPL at 1/2 m
    • Echo cancellation
    • Noise suppression
  • HDMI
    • USB Display Adapter: built-in USB 3.1 (Gen 1) to HDMI adapter
  • Connectivity
    • 12V/5A power adaptor
    • Mini DIN 6 for RS-232 connection
    • USB 3.1 Gen 1, backward compatible with USB 2.0
    • HDMI out connection (USB Display Adapter)
    • Phone in (3.5 mm audio Jack)/Speaker out for HA system*
    • Two RJ45 ports (one for Ethernet, one for audio expansion speakerphone/ microphone)
    • USB 2.0 Type-A*2 : One for Wireless connection**; one for IFP USB Touch back

    * Need to set up via PTZApp 2 and purchase an audio-out converter from AVer
    ** Wireless dongle (optional item) to connect with mobile phone
  • Environmental Data
    • Operation temperature: 0 ~ 40°C
    • Operation humidity: 20% ~ 80%
    • Storage temperature: -20 ~ 60°C
    • Storage humidity: 20% ~ 80%
  • Package Contents
    • VB342 Pro unit
    • Power cable 10 ft (3 m)
    • USB 2.0 Type-B to Type-A Cable 5m
    • USB 3.1 Type-A to Type-C adapter
    • QR code card
    • Wall-mount bracket and screws
    • Remote control
    • Wall-mount drill paper
  • Optional Accessories
    • Mini DIN 6 to RS-232 adapter
    • TV VESA mount for mounting on top of TV and beneath TV
    • Foldable TV mount
    • 10 m/20 m expansion microphone
    • 10 m/20 m expansion Speakerphone
    • 10 m/20 m/30 m USB 3.1 extender cable
    • 3 m USB 2.0 extender cable
    • Wireless dongle (for connecting with mobile phone)
    • Audio-out converter (TRS female to TRRS male)
  • Dimensions
    • Package dimensions: 872 x 197 x 260 mm
    • Package weight: 6.3 kg / 13.8 lbs
    • Camera: 738 x 127 x 116 mm / 3.1 kg
    • Remote control: 149.72 x 42.3 x 19.3mm / 50 g
  • Warranty*
    • Camera: 3 years
    • Accessories: 1 year

    *We offer an optional 2-year extended warranty in the European area. Please contact your local agency for details.
  • Compatible Applications
    • Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans , Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx® GoToMeeting™, LiveOn, Microsoft® Lync™, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit

    *For 4K UHD support, please check system/hardware requirements with your software application provider.

* Specifications may vary depending on countries and are subject to change without notice.

URL

Accessories

  • VB342 Pro
    VB342 Pro
  • Power Adapter and Power Cable (3m) Adapter PN:04131HGOOARC
    Power Adapter and Power Cable (3m) Adapter
  • Remote Control PN:0412U360-ASJ
    Remote Control
  • USB 2.0 Type-B to Type-A Cable (5m) PN:064AUSBCFF
    USB 2.0 Type-B to Type-A Cable (5m)
  • USB Type-A to Type-C Adapter PN:063AUB-UBAFL
    USB Type-A to Type-C Adapter
  • Wall-Mount Screws (x4)
    Wall-Mount Screws (x4)
  • Wall-Mount Bracket
    Wall-Mount Bracket
  • QR code card
    QR code card
  • PN:60U3300000AD(10m) PN:60U3300000AE(20m)
    10m / 20m Expansion Microphone
  • PN:60U3300000AB (10m) PN:60U3300000AC (20m)
    10m / 20m Expansion Speakerphone
  • PN: 064AUSB−−CC5 (10m) PN: 064AUSB−−CC6 (20m) PN: 064AUSB−−CDS (30m)
    10 m/20 m/30 m USB 3.1 Extension Cable
  • PN: 50U3300000AK
    (EU/JP/KR/RU/ZA/TH/IN/MY/PH)
    PN: 50U3300000AL (AU) PN: 50U3300000AJ (US/TW)
    Wireless Dongle
  • PN: 60U3210000AB
    TV VESA mount
  • PN: 064AUSBCCP
    3 m USB 3.1 Type-B to Type-A Cable
  • PN:064AOTHERB66
    Mini DIN 6 to RS-232 Adapter
  • PN:064AAUDIOCKB
    Audio out Convert Cable
  • PN: 60V2C10000A7
    Foldable TV Mount
  • * Please contact local authorized dealer/distributor for purchasing optional accessories.
