- Camera
-
- 4K optical lens, 120° FOV, up to 5X zoom via ePTZ*
- Sony 4K sensor: ultra-crystal-clear image in any lighting
- Frame rates: (16:9) 4K 30fps ; 1920 x 1080, 1600 x 900, 1280 x 720, 960 x 540, 848 x 480, 800 x 448,
640 x 360, at 60,
30, 15fps; (4:3) 1280 x 960, 800 x 600, 640 x 480 at 60, 30, 15fps
- Intelligent fill light: automatically adjusts lighting levels to make you look energetic in a
dim environment**
- SmartFrame: automatically adjusts FOV (auto focus) to track and fit all participants onscreen
- Innovative Preset Framing: Follows the presenter through preset areas
- True WDR up to 120db: 3D noise-reduction and superb backlight compensation optimize lighting in high-contrast conditions
- Mirror, flip, AE, white balance: auto/manual override via PTZApp2
- Minimum focus distance: 60 cm
- People-counting API: enterprises and third-party software providers can obtain people-counting
data for better
understanding of meeting-space usage
- 10 camera presets (through remote control and IP web page)
- Standard tripod screw holes
*Please use PTZApp 2 to set up 5X zoom.
**For best lighting results, sit within 1 meter away from the camera.
-
- Microphone
-
- 2 microphones
- Frequency response: 100–12K Hz
- Sensitivity: -37 dB
- Echo cancellation and background noise suppression
-
- Connectivity
-
- USB type-C 3.1 connector, backward compatible with USB 2.0
- DC jack for power adapter (for USB 2.0 connection while using fill-light function)
-
- Video Format
-
- YUV, YUY2, MJPEG
- H.264 (UVC 1.5)
-
- USB
-
- 3.1 Gen 1, backward compatible with USB 2.0
- UVC 1.1 (USB video), UAC 1.0 (USB audio), UVC1.5*
*UVC1.5 requires an additional firmware upgrade. Please contact technical support for more details.
-
- Control
-
- IR remote control
- UVC/UVA plug-and-play
- PTZApp 2
-
- Security and Mount
-
- Built-in TV clip
- Kensington slot
- 1/4" tripod mounting screw
-
- System Requirements
-
- Windows® 7/10/11
- MacOS X 14.4 or later
- Chromebox 3 version 94.0.4606.114 or later
-
- Hardware Specs
-
- 3.2 GHz Intel® Core™ i5-4460 processor
- 4 GB RAM or more
- USB 3.1 port, backward compatible with USB 2.0
-
- Power Supply
-
- AC 100V–240V, 50/60 Hz
- 5V/2A
-
- Free Applications for Meeting Collaboration
(For Windows® and Mac® computers)
-
EZManager 2: Camera Central Management Software
- Remotely group FW/SW upgrades, control the camera, and manage settings
PTZApp 2: Camera Settings Software
- View live video, people-counting numbers, and meeting-interval information
- Enable Skype for Business far-end control
- Upgrade firmware automatically or manually
- Control the camera
- Set parameters and adjust the camera image
- Diagnose operating status
EZLive: Broadcasting Software
- Enjoy multi-camera real-time streaming, annotating, image capturing, and video recording
-
- Environmental Data
-
- Operation temperature: 0 to 40°C
- Operation humidity: 20% to 80%
- Storage temperature: -20 to 60°C
- Storage humidity: 20% to 80%
-
- Dimensions
-
- Package dimensions: 217(L)*155(W)*118(H) mm
- Package weight: 0.729 kg
- Camera: 160 (L) x 37 (H) x 60 (D) mm/ 0.282kg
- Remote control: 149.72 x 42.3 x 19.29 mm/50g (optional item)
-
- Package Contents
-
- CAM130 unit
- Power adapter (10 ft/3 m)
- USB 3.1 type-C to type-A cable (6 ft/1.8 m)
- QR code card
- Tripod screw
-
- Optional Accessories
-
- Remote control (also compatible with VB130)
- USB 2.0 type-C to type-A cable (15 ft/5 m)
- USB 3.1 Extension Cable (10 m/20 m/30 m)
-
- Warranty
-
- Camera: 3 years
- Accessories: 1 year
-
- Compatible Applications
-
- Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans , Intel®
Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx® GoToMeeting™, LiveOn,
Microsoft® Lync™, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit
-
* For 4K UHD support, please check system/hardware requirements with your software application provider.
** Specifications may vary depending on countries and are subject to change without notice.
